Volkswagen Amarok NF (2023-Current) Under Bonnet Auxiliary Battery Mount - Pirate Camp Co
An under bonnet auxiliary battery mount for the Volkswagen Amarok NF (2023-Current). It fills the space set aside for a second battery under the bonnet, so a dual battery setup goes in without fabrication. Pirate Camp Co built…
Overview
- Internal tray dimensions 330mm long x 180mm wide
- Suits up to a Delkor HDC27 100Ah battery
- Suits the iTech World 120Ah lithium battery
- Provision to mount a REDARC 25A or 40A BCDC charger
- Maximum load rating 25kg
- Brand
- Pirate Camp Co.
- Product type
- Electrical
- SKU
- P-1815
Fitment and delivery
Check the fitment details in the product description against your vehicle before ordering. Model, year, variant and existing modifications can affect fitment.
Product details
What to know before ordering
Description, fitment and specifications
An under bonnet auxiliary battery mount for the Volkswagen Amarok NF (2023-Current). It fills the space set aside for a second battery under the bonnet, so a dual battery setup goes in without fabrication. Pirate Camp Co built it around the Delkor HDC27 100Ah battery, and it also takes lithium batteries up to 190mm high.
What vehicles does this fit?
| Make | Model | Variant | Body | Years | Fit |
|---|---|---|---|---|---|
| Volkswagen | Amarok NF | - | - | 2023-Current | Direct fit |
Key features
- Internal tray dimensions 330mm long x 180mm wide
- Suits up to a Delkor HDC27 100Ah battery
- Suits the iTech World 120Ah lithium battery
- Provision to mount a REDARC 25A or 40A BCDC charger
- Maximum load rating 25kg
Build and finish
- 304 grade stainless steel
- Texture black powder coat
- 100% Australian made and owned, per Pirate Camp Co
Before you order
Maximum battery size is 330mm long x 180mm wide x 200mm high, measured to the top in the middle. Terminal posts can sit higher because they sit off to the side. The washer bottle crosses the middle of the tray, which is what sets the height limit.
Pirate Camp Co note that any battery taller than 190mm raises the washer bottle filler. The filler then sits on an angle and rests on the battery. It still works, but filling is slower.
What's included
- Under bonnet auxiliary battery mount
Not included: the battery and the BCDC charger.
Frequently asked questions
Will a lithium battery fit?
Yes, as long as it is no taller than 190mm and fits the 330mm x 180mm tray. Pirate Camp Co list the iTech World 120Ah lithium as suitable.
Can I mount my BCDC on it?
Yes. The mount has provision for a REDARC 25A or 40A BCDC charger.
