Ford Ranger Super Duty (2025-Current) Dash Switch Cluster - Pirate Camp Co
A dash switch cluster for the Ford Ranger Super Duty (2025-Current) that puts switch positions in the fascia rather than under the dash. It uses the factory USB-A and USB-C socket position, so the dash is not cut.…
Overview
- Takes Toyota short switches, sold separately
- Uses the factory USB-A and USB-C socket position and retains the factory USB
- No modifications to the dash
- Switch cavity blanks available separately for unused positions
- Suits the Pirate Camp Co Toyota style UHF pass through connector
- Stainless steel with a texture matte black powder coat
- Brand
- Pirate Camp Co.
- Product type
- Electrical
- SKU
- P-2137
Fitment and delivery
Check the fitment details in the product description against your vehicle before ordering. Model, year, variant and existing modifications can affect fitment.
Product details
What to know before ordering
Description, fitment and specifications
A dash switch cluster for the Ford Ranger Super Duty (2025-Current) that puts switch positions in the fascia rather than under the dash. It uses the factory USB-A and USB-C socket position, so the dash is not cut. Stainless steel with a texture matte black powder coat.
What vehicles does this fit?
| Make | Model | Variant | Body | Years | Fit |
|---|---|---|---|---|---|
| Ford | Ranger Super Duty | - | All | 2025-Current | Direct fit |
| Ford | Next Gen Ranger (P703) | - | Dual Cab | 2022-Current | Does not fit |
| Ford | Next Gen Everest (U704) | - | Wagon | 2022-Current | Does not fit |
Key features
- Takes Toyota short switches, sold separately
- Uses the factory USB-A and USB-C socket position and retains the factory USB
- No modifications to the dash
- Switch cavity blanks available separately for unused positions
- Suits the Pirate Camp Co Toyota style UHF pass through connector
- Stainless steel with a texture matte black powder coat
Specifications
- Material: stainless steel
- Finish: texture matte black powder coat
- Switch type: Toyota short switch, sold separately
- Switch cavity blanks: 32mm high x 21mm wide, sold separately
Fitting and installation
Pop the factory USB-A and USB-C socket out, drop the bottom tab of the panel into that hole, then push in and up until the top of the panel clips into the air vents below the in dash screen. Nothing is cut and nothing is drilled. Most of the work is behind the dash, running the switch wiring back to a fuse block.
What's included
- Dash switch cluster panel
Not included: switches, blanking caps, wiring, relays and fusing.
Frequently asked questions
What switches does it take?
Toyota short switches, sold separately. Pirate Camp Co list theirs as suiting 2016 Toyota HiLux switch cut outs, with latching off and on operation, blue LED illumination and a connector supplied. Rocker switches with a different body size will not sit in the cut outs.
What if I am not using every position?
Pirate Camp Co sell switch cavity blanks that fit their clusters, 32mm high by 21mm wide, so empty positions still look finished.
Does fitting require cutting the dash?
No. The panel uses the factory USB socket position and clips into the air vents below the screen, so no holes are made and the factory USB is retained.
Will this affect my factory warranty?
Fitting an accessory does not void a vehicle warranty in Australia under Australian Consumer Law. A dealer can decline a claim where the accessory or the way it was installed caused the fault, so fuse and route accessory wiring properly and keep it clear of airbag components behind the dash.
