Ford Ranger PX1/PX2/PX3 & Raptor Gen 1 (2011-2022) Electric Side Steps - VIKOR
VIKOR INDUSTRIESPowered side steps for the Ford Ranger PX series. They swing out when you open the door and fold flat under the sill when you shut it. VIKOR state a 280kg load capacity, a trigger off the factory door sensor and a bolt-in fit to factory mounting points with no drilling.
What vehicles does this fit?
| Make | Model | Variant | Body | Years | Fit |
|---|---|---|---|---|---|
| Ford | Ranger PX1 | All variants | Dual Cab | 2011-2015 | Direct fit |
| Ford | Ranger PX2 / PX3 | All variants | Dual Cab | 2015-2022 | Direct fit |
| Ford | Ranger Raptor (Gen 1) | - | Dual Cab | 2018-2022 | Direct fit |
| Ford | Ranger Next Gen (P703) | - | Dual Cab | 2022-Current | Does not fit |
Side steps are cab-length specific. This is the dual cab fitment. Tell us your cab style if you are running a single or super cab PX and we will quote the right pair.
Key features
- Deploys on door open, retracts flat under the sill on close
- VIKOR state a 280kg load capacity
- VIKOR state the steps trigger off the factory door sensor
- VIKOR state they bolt into factory mounting points with no drilling
- VIKOR state a safety cut-out stops the step if a limb or object is caught during retraction
Fixed side steps solve the step-up problem and hand you a clearance problem in return. These do not. Retracted, the step tucks up under the sill so you keep the side clearance you started with. Extended, it drops the stepping height enough that loading kids or older passengers into a lifted ute stops being a production.
Specifications
| Type | Powered retracting side steps, sold as a pair |
| Load capacity | 280kg (VIKOR figure) |
| Trigger | Factory door sensor |
| Mounting | Factory mounting points, no drilling |
| Safety | Cut-out on obstruction during retraction |
| Fitment | Ford Ranger PX1, PX2, PX3 and Ranger Raptor Gen 1 dual cab |
Sensor and safety system compatibility
VIKOR state the steps run off the factory door sensor rather than a separate switch, and that a safety cut-out stops the step if a limb or an object is caught during retraction. The wiring is the part that touches the vehicle's electrics, which is why this is an installer job.
What's included
- Pair of powered side steps, driver and passenger side
Not included: installation, and colour coding of the trim to the vehicle. VIKOR state their authorised retailers can colour code the step trim, so contact us if you want that arranged.
Frequently asked questions
How much weight will they take?
VIKOR state a 280kg load capacity for the step. That covers a heavy adult carrying gear, and it covers standing on the step to reach the roof rack, which is what most people actually use it for. The rating is VIKOR's figure, not ours.
What happens if something is under the step when it retracts?
VIKOR state a safety cut-out is fitted, so the step stops if a limb or an object is caught during retraction. That matters if you have kids getting in and out, because the step is moving at the exact moment a door is closing.
Can I fit them myself?
VIKOR state they bolt into factory mounting points with no drilling, so the mechanical side is straightforward. The wiring is not. The steps need a power feed and a trigger from the factory door sensor, so factor in professional installation.
Will they fit a Ranger Next Gen?
No. VIKOR list these for the PX series and the Gen 1 Ranger Raptor, which ran from 2018 to 2022. The Ranger Next Gen (P703) launched in 2022 with a different sill and different mounting points. Contact us for the Next Gen fitment.
